Description and Application

The Hydraulic Telescopic Spreader SAUR was especially designed to safely streamline the shipment and handling of 20 and 40 foot containers. The drive is through two hydraulic cylinders, with valves that ensure their synchronism. It is made up of flaps installed on the corners to facilitate and speed up the attachment to the container. In addition, it holds a light indicator and sensors that signal when the spreader is correctly supported onto the container, to release the function lock.
This solution may be used in activities related to the sectors of agribusiness, railway, fertilizers, inputs, port, chemical & petrochemical, recycling and residues.

Specifications

  • Capacity: 35.000 kg.
  • Weight: 9.800 kg.
  • Width: 8 feet (2.260 mm).
  • Closed length: 20 feet (5.850 mm).
  • Open length: 40 feet (11.980 mm).
  • Height: 2.400 mm.
  • Rotation: 360°.
  • Capacity: Containers of 20 and 40 feet.
  • Hydraulic Unit (attached to the Spreader body): Motor: 5 CV.
  • Working pressure: 140 bar.
  • Double pump with 19,25 LPM, providing faster movements.
  • Tank capacity: 80l.
  • Lock: Mobile Flaps: installed on the 04 corners of the Spreader, facilitating and speeding up the attachment of the spreader to the container.
  • Twist-lock: responsible for the lock of the container to the Spreader, on the 04 sides. Hydraulically driven.
  • Drive system: Radio Frequency Remote Control.
  • Safety: Sensors that indicate whether the position of the container is correct and light indicators (according to the sensors).
