Container Dumper

Specifications

• Operating Mode: 1 - Truck parks under the gantry (guided by rails) 2 - Manual hitch of steel cables on the container with special hooks (regulated for containers) 3 - Elevation by cables activated hydraulically in the direction of the upper structure. Hydraulic locking through twist locks 4 - Manual opening of doors - at this time the container is still horizontal at ground level 5 - Hydraulic Tipping 6 - Filling of the container 7 - Activation of the gate retention device (keeps the doors closed by means of hydraulic force until container tipping to the horizontal position) /> 8 - Manual locking of the doors 9 - Unlocking of twist locks 10 - Placement on the truck 11 - Manual cable release
